How to copy dynamic volume?

2016-08-02 09:49:25 Posted by Daisy to Partition Master Guide

Summary:: EaseUS Partition Master can clone/copy dynamic volume to basic disk or convert dynamic disk to basic disk safely, then you can repartition/resize dynamic voume on this basic disk easily.

EaseUS Partition Master supports to copy dynamic volume, including simple volume, mirrored volume, striped volume, spanned volume and RAID-5 volume.

1. Download EaseUS Partition Master and install it. After that, launch EaseUS Partition Master.

DownloadWin Version

2. Select Wizard -> Copy dynamic volume

EaseUS Partition Master - Copy Dynamic Volume

3. EaseUS Partition Master will list all existing volumes. Select the source dynamic volume and click "Next".

Dynamic Volume Information

4. Choose an unallocated space on a basic disk and click "Next".

Select Destination Partition

5. Edit the destination partition, you can drag the borderline to resize partition or drag the central place to move the partition.

Edit Partition

6. Click "Finish", the operation will be added to "Pending Operations" panel on the main window.

Attention: If the dynamic disk you copy is not the system volume, ticking box in step 8 is not a must while step 9 and step 10 can be ignored.

7. Click "Apply" button and tick the check-box in the pop-up window.

Option to Shut down When Applying Changes

8. After rebooting and completing the operation, EaseUS Partition Master will shut down the computer automatically.

9. Replace the source dynamic disk that contains the system volume with the destination basic disk, and then boot the computer. (You may see the copy of C: partition has been extended.)
